HXD DESIGN GUIDLINE

FREE STANDING & MOUNTING

Some logos present challenges, like small icon with tight spacing or thin lettering. Our HXD designers analyze every detail of your logo, then create a solution. Having the minimum thickness and spacing are essential when working with small elements. If a solution can't be achieved through upsizing or subtle modification, we can use a mount solution.

Artwork Upsized To 3.75" W

Thickness required to be above 0.6" / 1.4mm

Spacing required to be above 0.4" / 1 mm

MOUNT OPTIONS

... CONTOUR IT !

Adding a contour base mount or

standard-shaped base mount will support

smaller elements like text and sharp points that can't be developed as freestanding HXD.

... DEFINE IT !

Adding an outer channel to your base mount builds your logo for even more body. Try a classic tonal look or colour accent.

... CREST IT !

Get a distinctive crest feel for your logo with a base mount with multiple outer channels and don't forget some texture fill.

TEXTURING

COLOURS & SPECIALITY COLOURS

FINISHING

STANDARD

MATTE FINISH

SPECIALITY

SOMETHING DIFFERENT

METALLIC

ALL LUSTER

HXD PROCESS

The dimensioning process prepares your art for reproduction in HXD. There are three steps combining artistic design, expertise and high-tech mechanical processes. Dimensioning is done by skilled designers who've been trained in the process and there is an associated fees.

You send us your vector art.

Our team creates a "Two Dimensional" line art representational logo.

A "3 Dimensional" colour rendering is created to bring the HXD to life.

HXD VIDEO
